Ubiquiti PrismStation AC PS-5AC 802.11ac 450 Mbit/s Wireless Bridge - PS-5AC-US

SKU:
PS-5AC-US
Shipping:
Calculated at Checkout
$299.00 $280.95
(You save $18.05 )

Call 805-522-9123

Image may not exactly match the product.

$299.00 $280.95
(You save $18.05 )

Call 805-522-9123

Availability:
Out of Stock.  Contact us for Back-Order Options

Condition:
New
Warranty Information
1 Year

Done shopping? You can create a PDF of your cart for later or for your purchasing dept! Details at checkout.

Share:
Specifications
Manufacturer: Ubiquiti Networks, Inc
Manufacturer Part Number: PS-5AC-US
Manufacturer Website Address: http://www.ubnt.com
Brand Name: Ubiquiti
Product Line: PrismStation AC
Product Model: PS-5AC
Product Name: PrismStation PS-5AC Wireless Bridge
Marketing Information:

Shielded airMAX® ac BaseStation with airPrism® Technology

With a die-cast aluminum base and interchangeable antenna, the PrismStationTM AC, brings increased performance to your network using technology that isolates beam communications between your devices. Utilizing Ubiquiti's advanced airMAX® ac processor, the PrismStationTM delivers throughput speeds up to 500+ Mbps and signal ranges up to 5+ km (3+ miles).

Built to Fight Noise With Prism Active RF Filter

The Ubiquiti R&D team designed airPrism filtering as a robust solution for tower co-location interference. Requiring no communication between radios - and functioning despite noise from other vendors' radios (unlike GPS synchronization) - airPrism enables greater system capacity and overall throughput by further reducing out-of-band energy.

Modular Design

The antenna horn is interchangeable and helps with beam-shaping for specific deployment and environment needs. The PrismStationTM AC also gets maximum gain out of the smallest footprint.

Beam Performance Perfected

The PrismStationTM can use a variety of horn antenna sectors designed for increased co-location performance without sacrificing gain. Its unique beam performance and superb co-location characteristics allow for a higher density of sectors than traditional sector technology.

GPS Synchronization

PrismStationTM AC supports GPS Sync for faster, more scalable, carrier-class networks, with 90% higher throughout than competing solutions.

Enhanced Co-Location

Asymmetrical horn antenna options (60° and 90°) have naturally attenuated side lobes and extremely low back radiation, and they offer industry-leading front-to-back ratio and low side lobe radiation. Symmetrical horn antennas (30° and 45°, the default) are ideal for cluster sector installations with high co-location requirements.

Improved Noise Immunity

PrismStationTM AC blocks or spatially filters out noise, so noise immunity is improved. This feature is especially important in an area crowded with other RF signals of the same or similar frequency.


Product Type: Wireless Bridge
Technical Information
Wireless LAN Standard: IEEE 802.11ac
Frequency Band: 5 GHz
Wireless Transmission Speed: 450 Mbit/s
Interfaces/Ports
Ethernet Technology: Gigabit Ethernet
Number of Network (RJ-45) Ports: 1
PoE PD Port: Yes
VGA: No
HDMI: No
USB: No
Powerline: No
Management Port: No
Physical Characteristics
Form Factor: Pole-mountable
Height: 7.2"
Width: 6.9"
Depth: 6.9"
Weight (Approximate): 2.36 lb
Miscellaneous
Package Contents:
  • PrismStation PS-5AC Wireless Bridge
  • 24V, 1A Gigabit PoE Adapter
  • Pole-Mount Kit

Warranty
Limited Warranty: 1 Year
