Intel C741 Chip - 8 TB DDR5 SDRAM DDR5-5600/PC5-44800 Maximum RAM Support - 32 Total Memory Slots - SD - 12Gb/s SAS Controller - G200e 8 MB Graphic(s) - Network (RJ-45) - Processor Support (Xeon Bronze, Xeon Silver, Xeon Gold, Xeon Platinum) - Gigabit Ethernet - Windows Server 2022 Standard, Windows Server 2022 Datacenter, Windows Server 2019 Standard, Windows Server 2019 Datacenter, Red Hat Enterprise Linux, SuSE Linux Enterprise Server Supported Operating System - 2
The Cisco UCS C240 M7 SFF server extends the capabilities of Cisco's Unified Computing System portfolio in a 2U form factor with the 5th Gen. Intel® Xeon® Scalable Processors, 16 DIMM slots per CPU for DDR5-5600 Memory DIMMs with DIMM capacity points up to 256GB or 4th Gen. Intel® Xeon® Scalable Processors, 16 DIMM slots per CPU for DDR5-4800 Memory DIMMs with DIMM capacity points up to 256GB.
The Cisco UCS C240 M7 SFF server harnesses the power of the latest Intel® Xeon® Scalable Processors , and offers the following:
CPU:
- Up to 2x 5th Generation Intel® Xeon® Scalable Processors with up to 64 cores per processor or
- Up to 2x 4th Generation Intel® Xeon® Scalable Processors with up to 60 cores per processor.
Memory:
- Up to 8TB with 32 x 256GB DDR5-5600 DIMMs, in a 2-socket configuration with 5th Gen. Intel® Xeon® Scalable Processors or
- Up to 8TB with 32 x 256GB DDR5-4800 DIMMs, in a 2-socket configuration with 4th Gen. Intel® Xeon® Scalable Processors.
The server provides one or two internal slot for one of the following:
- Cisco 24G Tri-mode RAID controller1 with cache backup to control SAS/SATA/NVMe drives or
- Cisco 12G RAID controller with cache backup to control SAS/SATA drives or
- Cisco 12G SAS pass-through HBA to control SAS/SATA drives
mLOM: The UCS C240 M7 SFF server has a single 1GBE management port. A modular LAN on motherboard (mLOM)/OCP 3.0 module provides up to two 100GBE ports. A connector on the front of the chassis provides KVM functionality.
