Cisco Nexus NIC HPT - Expansion Module - PCIe 3.0 X8 Low Profile - 10 Gigabit SFP+ X 2 - NXN-HPT=

SKU:
NXN-HPT=
Shipping:
Calculated at Checkout
$7,161.83 $6,300.53
(You save $861.30 )
NXN-HPT=

Image may not exactly match the product.

SPECIAL ORDER ONLY - THIS ITEM IS CURRENTLY AVAILABLE FOR PURCHASE, THOUGH THE ETA DEPENDS ON CISCO'S AVAILABILITY THROUGH DISTRIBUTION CHANNELS. FEEL FREE TO CONTACT US VIA PHONE, CHAT, OR SELECT "REQUEST A QUOTE" TO INQUIRE ABOUT AVAILABILITY.

Currently available for Pre-Order only

Check details for availability or request a quote

$7,161.83 $6,300.53
(You save $861.30 )
Availability:
This product is currently only available for pre-order

Condition:
New
Network Protocols:
10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Device Type:
Expansion module
Product Line:
Cisco Nexus
Connectivity Type:
Wired
Model:
NIC HPT
Host Interface:
PCI Express 3.0 x8

Done shopping? You can create a PDF of your cart for later or for your purchasing dept! Details at checkout.

Share:
  • Scalable and programmable
    For demanding capture applications, load balancing automatically distributes flows across a collection of receive queues to make the most of CPU parallelism. For those who need more control, flow steering directs traffic to specified threads or cores based on programmable rules.
  • Industry-standard synchronization
    The Cisco Nexus NIC HPT Pulse-Per-Second (PPS) input can be used to synchronize the HPT clock with a PPS source such as a Grand Master and/or GPS receiver to within 1ns, allowing users to meaningfully compare captured timestamps across multiple servers and/or geographic locations. The Cisco Nexus NIC HPT can also generate PPS output to master other devices in a rack and hardware assists Precision Time Protocol (PTP IEEE1588) packets for 2ns time synchronization across machines.
  • Ultra-low-latency performance
    The Cisco Nexus NIC HPT is also an ultra-low-latency network interface card. Designed from the ground up to minimize latency, the Cisco Nexus NIC HPT delivers great performance.
  • Easy to use
    The Nexus NIC HPT transparent socket acceleration library allows applications to benefit from the low latency of kernel bypass, in most cases without modifications to the applications. For the most latency-sensitive applications, a library allows for direct low-level access to the Nexus NIC hardware and includes simple functions for sending and receiving Ethernet frames.

Supports full line-rate capture with High Resolution Timestamps (HPT). High-speed capture can be performed to both standard PCAPs (with nanosecond resolution) and enhanced PCAPs (with picosecond resolution) using the Exact Capture software. Timestamps are also delivered directly through intuitive C- and Python-based APIs.
