Cisco Business 220 Series CBS220-8P-E-2G Ethernet Switch
Product Overview
The Cisco Business 220 Series CBS220-8P-E-2G Ethernet Switch is a smart, manageable network solution designed for small to medium-sized businesses that require robust connectivity with Power over Ethernet Plus (PoE+) capabilities. This rack-mountable switch provides 8 Gigabit Ethernet ports with PoE+ and 2 Gigabit SFP uplink slots, supporting both optical fiber and twisted pair media types.
Technical Specifications
- Product Type: Ethernet Switch
- Brand Name: Cisco
- Product Series: 220
- Product Model: CBS220-8P-E-2G
- Form Factor: Rack-mountable
- Dimensions: Height: 1.7", Width: 11", Depth: 6.7"
- Weight: Approximately 2.60 lb
Interfaces/Ports
- Total Number of Network Ports: 8
- Network (RJ-45): Yes
- Uplink Port: Yes
- Port/Expansion Slot Details:
- 8 x Gigabit Ethernet PoE
- 2 x Gigabit Ethernet Expansion Slot
- Modular: Yes
Media & Performance
- Ethernet Technology: Gigabit Ethernet
- Network Technology:
- 10/100/1000Base-T (Twisted Pair)
- 1000Base-X (Optical Fiber)
- Media Type Supported: Optical Fiber, Twisted Pair
I/O Expansions
- Number of Total Expansion Slots: 2
- Expansion Slot Type: SFP (mini-GBIC)
- Number of SFP Slots: 2
Power Description
- Power Source: Power Adapter
- Power Consumption: 8.20 W
- Frequency: 50 Hz, 60 Hz
- PoE (RJ-45) Port: Yes
- PoE Budget: 65 W
Management & Protocols
- Manageable: Yes
- Layer Supported: 2
Package Contents
- Business CBS220-8P-E-2G Ethernet Switch
- Adaptor
- Mounting Kit
- Quick Start Guide
Additional Features
- Environmentally Friendly: Yes
- Country of Origin: China
- Warranty: 3-Year Limited Warranty
Manufacturer Information
- Manufacturer: Cisco Systems, Inc
- Manufacturer Part Number: CBS220-8P-E-2G-NA
Description
The Cisco Business CBS220-8P-E-2G is designed for businesses that require a high-performing network with scalable options. This switch delivers advanced features such as Power over Ethernet Plus, which allows the switch to power connected devices like IP cameras and wireless access points directly through the network cable, eliminating the need for additional power supplies. This feature is particularly beneficial for expanding networks in areas where power outlets are scarce.
This switch also includes advanced management capabilities, allowing for easy setup and configuration. Its environmental friendliness and adherence to regulatory standards make it a sustainable choice for your business infrastructure, helping to reduce power consumption while maintaining high operational efficiency. The compact form factor and robust performance of the CBS220-8P-E-2G make it an excellent choice for businesses looking to enhance their network capabilities efficiently.
