Cisco QSFP-DD Module - For Data Networking, Optical Network - 1 x LC 400GBase-ZR Duplex Network - Optical Fiber400 Gigabit Ethernet - 400GBase-ZR - DP04QSDD-HK9=
- SKU:
- DP04QSDD-HK9=
- Shipping:
- Calculated at Checkout
$24,948.12
Financing Available: Learn More!
Image may not exactly match the product.
Done shopping? You can create a PDF of your cart for later or for your purchasing dept! Details at checkout.
Hear What Our Customers Are Saying
What Sets Us Apart
Real Humans. Real Help.
Forget chasing down reps or emailing into the abyss. Get your own IT Concierge — a real human who stays with you from start to finish. One point of contact. Zero runaround.
Rapid-Fire Quotes, No Fluff
Under the gun? We turn around Cisco & Meraki quotes in record time — even complex builds. No waiting days for basic pricing.
👉
Get My Fast Quote
Free Solution Design with White Glove Engineers
Need to validate your BoM or double-check your plan? Our Cisco-certified engineers review it with you, optimize where needed, and catch gotchas before they cost you…all free.
We Don’t Just Sell Boxes. We Build Solutions.
Pre-config, licensing help, and install guidance — we make sure what you buy solves your problem, the first time.
Trade-In Credits Without the Headaches
Turn your old gear into instant quote credits. We can coordinate the recycling or destruction in an environmentally friendly and safe manner. Enjoy a smoother path to your upgrade with built-in savings.
Unlock Pricing Other Buyers Don't See
Get access to exclusive Cisco/Meraki incentives, special pricing tiers, and project-based discounts you won’t find anywhere else.
Want to skip the back and forth? Talk directly to a specialist and get expert guidance in under 30 minutes.
For Data Networking, Optical Network - 1 x LC 400GBase-ZR Duplex Network - Optical Fiber400 Gigabit Ethernet - 400GBase-ZR
Cisco offers a comprehensive range of pluggable optical modules in the Cisco® pluggables portfolio. The wide variety of modules gives you flexible and cost-effective options for all types of interfaces. Cisco offers a range of GBIC, SFP, XFP, SFP+, CXP, CFP, Cisco CPAK, and QSFP+ pluggable modules. These small, modular optical interface transceivers offer a convenient and cost-effective solution for an array of applications in the data center, campus, metropolitan-area access and ring network, storage area network, and long-haul network. In recent times, with longer strides of innovation, Cisco has introduced Digital Coherent 400G DWDM ZR+ as well as interfaces to the market. The latest addition to the Cisco portfolio pushes this boundary further with the introduction of the 400G QSFP-DD High-Power (Bright) Optical Module.DP04QSDD-HE0
Product overview
Cisco is now expanding the range of 400G Digital Coherent QSFP-DD transceivers, introducing High Tx Power variants (+1dBm of Tx Power). Thanks to the miniaturization of the technology with a 7-nm manufacturing procedure and innovation in silicon photonic technology, it is now possible to also squeeze an Optical Amplifier (Mini-EDFA) within a QSFP-DD form factor.
Cisco 400G QSFP-DD High-Power (Bright) Optical module's small size and low power make it an optimal choice for a wide range of DCI/Cloud, metro access/aggregation, wireless backhaul, and campus interconnect applications.
Cisco 400G QSFP-DD High-Power (Bright) Optical module is mechanically compliant to the QSFP-DD Type 2A Module Specification. The QSFP-DD module contains a PCB with a 76-contact card-edge electrical interface to external host-side logic. The media interface is a duplex LC connector coupled to a 1550-nm optical fiber carrying the DP-mQAM coherent signal. The signaling operates in the C-band.
Two product variants are available:
- 1.Ethernet Variant (DP04QSDD-HE0)
- 2.Multirate OTN/Ethernet Variant (DP04QSDD-HK9)
Cisco 400G QSFP-DD High-Power (Bright) Optical Module Ethernet Variant Overview
Cisco 400G QSFP-DD High-Power (Bright) Optical module Ethernet variant is an enhanced version of the currently available QSFP-DD ZR+ Optical Module leveraging the same operational modes but providing as a major enhancement the increase of the Tx Optical Power up to +1dBm (EoL).
Supported client interface for this pluggables is Ethernet based, making this model perfectly suitable to be hosted on a router/switch host. The module asynchronously (GMP) maps an Ethernet signal from a switch/router to an intermediate 400ZR frame structure and then adapts the frame structure to the appropriate FEC engine. The encoded signal is subsequently DSP framed and modulated for transmission as a coherent Dual-Polarity mQAM signal.
Cisco 400G QSFP-DD High-Power (Bright) Optical Module Multirate Ethernet/OTN Variant Overview
The Cisco 400G QSFP-DD High-Power (Bright) Optical module multirate Ethernet/OTN variant shares the same HW platform (and so also the high Tx power) of the Ethernet variant but also supports OTN clients. The module leverages an intermediate ODUFlex,OTUCn/FlexO-x frame structure and then adapts the frame structure with OFEC.
- Availability: Currently out of stock, pre-order may be available
- Condition: New
- Warranty Information 1 Year
- Ethernet Technology: 400 Gigabit Ethernet
- Network Technology: 400GBase-ZR
- Product Type: QSFP-DD
